Display |
5 digits ( 0 to 99999 ) LCD display. |
|
Circuit |
Exclusive one-chip design microprocessor LSI circuit. |
|
Measurement |
FPM ( rotation per minute ). Build in external trigger input. |
|
Sampling Time |
Approx. 1 second. |
|
Calibration |
Crystal time base and microprocessor circuit, no external calibration process required. |
|
Operating Temperature |
0 to 50 ℃ ( 32 to 122℉ ) |
|
Humidity |
Less than 80% R.H. |
|
Power Supply |
DC 1.5 V, UM-1 (D type) battery x 4 PCs * DC 9V adapter input is built, AC/DC adapter is opional, not in included. |
|
Power Consumption Weight Dimensions |
Stroboscope ( 3600 FPM ) : DC 160 mA. |
|
800 g ( 1.76 LB ). 21 cmx12 cmx12 cm (8.3"x4.8"x4.8"). |
|
|
Accessories Included |
Operation manual............................................................ 1 PC. |
|
Optional Accessories |
ACV 110V, 220/230V to DC 9V adapter. |
E ELECTRICAL SPECIFICATIONS
|
Stroboscopic Flash Rate |
100 to 99,999 flashes per minute (FPM). Low range : 100 to 1,000 RPM/FPM. High range : 1000 to 99,999 RPM/FPM. |
|
Accuracy |
± ( 0.05% + 1 digit ). |
|
Resolution |
0.1 FPM/RPM (less than 1,000 FPM/RPM) 1 FPM/RPM ( > 1,000 FPM/RPM ). |
|
Light Source |
Long life high intensity LED array. |
