Scan Specifications
Back to topScanner Type: Flatbed color image scanner
Optical Sensor: Color Epson MatrixCCD™ line sensor
Optical Resolution: 2400 dpi
Hardware Resolution: 2400 x 4800 dpi with Micro Step Drive™ technology
Maximum Resolution: 12,800 x 12,800 dpi
Effective Pixels: 87,840 pixels / line (2400 dpi)
Color Bit Depth: 48-bit internal / external1
Grayscale Bit Depth: 16-bit internal / external1
Optical Density: 3.8 Dmax
Maximum Scan Area: 12.2" x 17.2"
Light Source: Xenon gas cold cathode fluorescent lamp
Focus Control: AutoFocus optics system (CCD and lens unit)
Transparency Adapter
Back to topTransparency Size: 12.2" x 16.5"
Supported Film Size:
- 35 mm mounted slides
- 35 mm film strips
- Medium format transparencies
- 4" x 5" film
Features
Back to topButtons: 1 button: Start
Software:
- Epson Scan with Epson Easy P******o Fix™ Technology
- Adobe® P******oshop® Elements
- LaserSoft® Imaging SilverFast® Ai and IT8 Target
Accessories:
- 12.2" x 16.5" Transparency Adapter with holders for 35mm slides, film strips, 4" x 5" and medium format transparencies (included)
Connectivity
Back to topScanner Interface: Hi-Speed USB 2.0
Operating Systems:
General
Back to topReliability: MCBF: 100,000 cycles
Operating Temperature: 41° to 95° F (5° to 35° C)
Operating Humidity:
- Operating
- 10% – 80% Storage
- 10% – 85% (no condensation)
Rated Voltage: AC 100 – 120 V, 220 – 240 V
Frequency: 50 – 60 Hz
Power Consumption:
- Without optional unit: 45 W
- With optional unit: 55 W
Dimensions: 25.8" x 18" x 6.2" (W x D x H)
Weight: 28.7 lb
Notes
1 External bit depth is selectable depending on the image editing software
