TECHNICAL DATA:
Required power: 230V/1 or 400/3+N/50 Hz
Water feeding: hosepipe ø 13 mm
Steam inlet: 1/2
Return outlet: 1/2
Air inlet: 3/8
Steam working pressure: 5 bar
Air working pressure: 7 bar
Steam consumption: 16÷20 Kg/h
Air consumption: 10 NL/MIN
Central vacuum connect.: ø 48 mm
Vacuum depression: 200 mm H²o
Vacuum air consumption: 360 m³/h
Boiler drain: 1/2
Vacuum outlet: ø 100 mm
Boiler heating: 10÷12÷15÷18 KW
Iron heating element: 0.8 Kw
Vacuum motor: 0.37 Kw
Pump motor: 0.6 Kw
Compressor motor: 1.10 Kw
Encumbrance: 1250 x 1150 mm
Gross weight: 390 kg
