| Cập nhật: 12/10/2020 - 14:53 | Tình trạng: Mới |
| Bảo hành: 24 Tháng | Nguồn gốc: Chính hãng |
| Hãng sản xuất | ZEBEX |
| Công nghệ quét | Laser |
| Tốc độ quét | 100 scan/s |
| Chiều rộng mã vạch tối thiểu | 5 mil @ PSC = 90% |
| Số tia quét | 1 |
| Cổng kết nối | • PS/2 • USB • RS232 |
| Tính năng | Light Source
Depth of Field
Scan Rate
Number of Scan Lines
Minimum Bar Width
Print Contrast
Indicators (LED)
Beeper Operation
System Interfaces650 nm visible laser diode (VLD)
15 – 260 mm (UPC/EAN 100%, PCS=90%)
100 scans per second
Single
5 mil @ PCS=90% (0.1 mm actually)
30% @ UPC/EAN 100%
Three-color LED (green, red & blue)
Programmable tone & beep time
Keyboard, RS-232C, HID USB, wand
PHYSICAL
Dimensions
Weight
Cable(L)106.7 × (D)58.0 × (H)155.0 mm (device only)
200 g (stand excluded); 563 g (stand included)
Standard 2.0M straight
ELECTRICAL
Input Voltage
Battery
Operating Autonomy
Recharge Time9V DC 1A at charging
2 AA NiMH rechargeable batteries
Over 24,000 reads at full charged by scanning once per 10 seconds
5 hours (max.)
RADIO COMMUNICATION
Protocol
Radio Frequency
Working RangeSerial Protocol Profile (SPP)
2.4 – 2.48 GHz
Up to 100M / 75M (depends on operating environment)
REGULATORY
Laser Class
EMC
RadioCDRH Class II; IEC 60825-1: Class 1
CE & FCC DOC compliance
FCC TCB, EN 300 328, ARIB STD-T66
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Humidity
Light Levels
Drop Durability
0°C – 40°C (32°F – 104°F)
-20°C – 60°C (-4°F – 140°F)
5% – 95% RH (non-condensing)
4,500 Lux (fluorescence)
Designed to withstand 1.0M drops |
| Kích thước (mm) | 106.7x58x155 |
| Trọng lượng (g) | 200 |
| Xuất xứ | Taiwan |
