LOW RATE TO 712 LPM (188 GPM)
MAX PRESSURE = 8.6 BAR (125 PSIG)
WETTED HOUSINGS
(Liquid Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 35 kg (78 lbs) |
| Alloy C | 54 kg (119 lbs) |
| Stainless Steel | 53 kg (117 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Section | Aluminum, Stainless Steel |
| Air Valve | Aluminum, Stainless Steel |
MAXIMUM SUCTION LIFT CAPABILITY
7.4 m (24.4') Dry
MAXIMUM DIAMETER SOLIDS
6.4 mm (1/4")
ELASTOMER OPTIONS
| Material | Temperature Limits |
| Buna-N® | -12.2 (+10) to +65.6 (+150) °C (F°) |
| Neoprene | -17.8 (+0) to +93.3 (+200) °C (F°) |
| EPDM™ | -51.1 (-60) to +137.8 (+280) °C (F°) |
| Polyurethane | -12.2 (+10) to +65.6 (+150) °C (F°) |
| Saniflex™ | -28.9 (+20) to +104.4 (+220) °C (F°) |
| PTFE | +4.4 (+40) to +104.4 (+220) °C (F°) |
| Viton® | -40 (-40) to +176.7 (+350) °C (F°) |
