| Grinding capacity (Min.-Max.) | φ120 ~ φ800mm | |
| Motor | Grinding wheel | 1HP |
| Cooling system | 1/6HP | |
| Clearance & hook angle motor | 0.5KW | |
| Grinding wheel feeding | Hydraulic driving ( for Hydraulic driving) | |
| Hydraulic pump | 2HP | |
| Tooth pushing | 0.4KW | |
| Angle | Clearance Angle | 5° ~ 45° |
| Hook Angle | -7° ~ +40° | |
| Bevel grinding top angle | 5° ~ 45° | |
| Bevel grinding face angle | 0° ~ 30° | |
| Grinding speed | 0 ~ 10mm/s | |
| Speed of tooth pushing | 10 T/min | |
| Grinding path | 20mm | |
| Blade thickness (steel plate) | up to 5mm | |
| Tooth Pitch | 6mm ~ 80mm | |
| Diamond Wheel (Dia.x bore) | φ125 x φ32mm | |
