| Manufacturer | EP | EP | EP | |
| Model designation | ES-14-14AX | ES-16-16AX | ES-16-16STX | |
| Drive unit | Battery | Battery | Battery | |
| Operator type | Walkie/ Rider | Walkie/ Rider | Walkie/ Rider | |
| Load capacity | Q (kg) | 1400 | 1600 | 1600 |
| Tyre type | PU/PU | PU/PU | PU/PU | |
| Height, mast lowered | h1 (mm) | 1980/ 2135/ 2335/ 2500 | 1980/ 2135/ 2335/ 2500 | 2135 |
| Lift height | h3 (mm) | 3000/ 3300/ 3600/ 4000 | 3000/ 3300/ 3600/ 4000 | 4000/ 4500/ 5000 |
| Height of straddle arms or load wheel casing | h8 (mm) | 100 | 100 | 100 |
| Fork height, lowered | h13 (mm) | 85 | 85 | 85 |
| Overall length (out leg/ fork) | l1 (mm) | 1995 | 1995 | 2055 |
| Overall width | b1/ b2 (mm) | 1470 | 1470 | 1470 |
| Fork dimensions | s/ e/ l (mm) | 40/100/1050 | 40/100/1050 | 40/100/1050 |
| Fork carriage width | b3 (mm) | 812 | 812 | 812 |
| Width between straddle arms | b4 (mm) | 1270 | 1270 | 1270 |
| Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2260 | 2260 | 2260 |
| Aisle width, 800×1200 pallet lengthways | Ast (mm) | 2230 | 2230 | 2230 |
| Outer turning radius | Wa (mm) | 1975/ 1565 | 1975/ 1565 | 2040/ 1630 |
| Travel speed, laden/ unladen | km/ h | 3-5 / 3-5 | 3-5 / 3-5 | 3-5 / 3-5 |
| Lifting speed, laden/ unladen | m/ s | 0.13 / 0.23 | 0.13 / 0.23 | 0.13 / 0.23 |
| Lowering speed, laden/ unladen | m/ s | 0.13 / 0.23 | 0.13 / 0.23 | 0.13 / 0.23 |
| Maximum gradeability, laden/ unladen S2 5 min. | % | 5/ 7 | 5/ 7 | 5 / 7 |
| Drive motor rating S2 60 min. | kW | 1.5 | 1.5 | 1.5 |
| Lift motor rating at S3 15% | kW | 3 | 3 | 3 |
| Battery voltage/ rated capacity (5h) | V/ Ah | 24/ 280 | 24/ 280 | 24/ 280 |
| Battery weight (with box) | kg | 228 | 228 | 228 |
| Type of drive control | AC | AC | AC | |
| Manufacturer | CURTIS | CURTIS | CURTIS | |
| Steering | Power steering | Power steering | Power steering |
