Code
|
Description
|
|
SWM
|
WeiMonitor PC program for monitoring and recording in real time all the weighs executed on the connected scale.
|
|
MSTSLV
|
Optional program for using the indicator as a universal weight repeater or as a multi-scale repeater (MASTER) in combination with the DFW/DGT/MCW.
|
|
RFITR
|
Integrated 868 MHz radio frequency module on the indicator, complete of RS232 port. Max. functioning distance in appropriate environmental and installation conditions: 70m indoors, 150m outdoors. Up to 50 configurable channels.
|
|
 OBRF
|
External 868 MHz radio frequency module for weight indicator/repeater, with ABS IP65 protecting box and 3 m RS232 connecting cable; power supply from weight indicator/repeater. Max. functioning distance, in appropriate environmental and installation conditions: 70m indoors, 150m outdoors. 50 configurable channels. (OBRF must be combined with another radio module).
|
|
OBRFUSB
|
868 MHz radio frequency module for PC, with PVC box and 1 m USB/mini USB connecting cable; power supply directly from the USB port. Max. functioning distance, in appropriate environmental and installation conditions: 70m indoors, 150m outdoors. 50 configurable channels. (OBRFUSB must be combined with another radio module).
|
|
OBRF232
|
868 MHz radio frequency module for PC, ABS IP65 protecting box, 3 m RS232 connecting cable, complete with DB9 pin connector and external power supply. Max. functioning distance, in appropriate environmental and installation conditions: 70m indoors, 150m outdoors. 50 configurable channels. (OBRF232 must be combined with another radio module).
|
|
ALMEM
|
Alibi memory (fiscal memory, max 120.000 weighs) for approved transmission of the weight to PC/PLC. Real time clock integrated for print of the date/time.
|
|
TPRP
|
Thermal printer for panel mounting with connection cable, 5V power supply (power adapter not included).
|
|
DFCLK
|
Real time clock for printing/displaying of the date and time.
|
|
WIFIT
|
WI-FI interface for wireless connection (through access point) to the company computer system.
|
|
MCWHSH
|
Thermal shield for protection from high temperatures (the crane scale can function with a max. environment temperature of 80°C. The thermal shield prevents the heat (in the form of infrared rays) beneath the shield to quickly increase the crane scale temperature. With the thermal shield it is possible to quickly pass over heat sources having a strong infrared ray emission. The amount of time which it can be above these sources depends on the type of source energy and the distance of the crane scale from it.)
|
|
MCWHBK
|
Additional extractable battery kit, rechargeable, for 24/7 continuous use of the crane scale and battery charger with light indication of the status. Ready for use with the power supply of the crane scale.
|
|
EEAC
|
ACCREDIA - EA (European Accreditation) calibration certificate for crane scales with capacity starting from 3000 kg. NET PRICE
|
