| Main Board | 16 bit CPU , 8 Mb high-speed CACHE Memory |
| Control Panel | 2X16 character LCD display , 8-keys soft keyboard |
| Drive | Stepping motor and micro-step driver |
| Acceptable Media Width | 730mm |
| Max.Cutting Area | Width : 630mm Length : 25000mm |
| Max.Cutting Speed | 500mm /s |
| Max.Cutting thickness | 1mm |
| Cutting Force | 0 to 500g(digital adjustment) |
| Mechanical Resolution | 0.025mm |
| Repeatablity | Within 0.1mm |
| Blade Type | Sweden SANDWIK professional alloy –steel blade |
| Offset | 0~1mm |
| Instruction system | HPGL / DMPL |
| Interface | RS 232C (standard RS 232 ) |
| Buffer Size | 8 Mb |
| Power Supply | AC220 50Hz / AC110V 60Hz |
| Power Consumption | <100VA |
| Operation Temperature | 5 to 40 °C (41 to 104 °F ) |
| Operating humidity | 35% to 80% ( non-condensing ) |
| External Dimension | 1030mm (W)x 375mm (D)x 380mm (H) |
| Weight | 18kgs |
