Model |
APL1000 |
APL2000 |
|
|
Motor power rating |
1/2HP 550kg max. |
1HP 1000kg max. |
|
|
Output |
Capacity |
1000VA |
2000VA |
|
Start capacity |
3KVA |
5.5KVA |
|
|
Voltage |
Same as input nominal |
||
|
Regulation |
Vrms +/- 5% |
||
|
Frequency |
50/60Hz |
||
|
Waveform |
PWM Step Wave |
||
|
Input |
Voltage |
220V |
|
|
Frequency |
50/60Hz +/- 3% |
||
|
Battery |
Battery voltage |
24Vdc |
24Vdc |
|
Spec. / PCS |
12V 7Ah * 2pcs |
12V 9Ah * 2pcs |
|
|
Type |
Lead-acid maintenance free |
||
|
Backup |
No Load |
60 hours |
60h hours |
|
Half Load |
25~35 min. |
30~45 min. |
|
|
Full Load |
10~17 min. |
15~22 min. |
|
|
Protection |
Over voltage |
Yes |
|
|
Under voltage |
Yes |
||
|
Surge |
Line filter & surge suppression meet IEEE-587, Cat. A |
||
|
Noise |
Varistor clamping 150 joules. Response Greater then 20dB and over 1MHZ range for common & transverse modes |
||
|
Overload |
Fuse & current limited & cut off |
||
|
Short circuit |
Fuse & current limited & cut off |
||
|
Low battery |
No battery drain after cut off |
||
|
Indicator |
Audible |
Beeping alarm; Low battery & Overload |
|
|
Visible |
AC SW LED Indicate; AC SW ON : light; AC SW Off : dark |
||
|
Cold start |
Without AC present, force UPS by pushing reset SW |
||
|
Emergency light outlet |
Install a bulb, Bulb will light while AC failure |
||
|
Environment |
Temperature |
1~40 degree C |
|
|
Humidity |
0~90% non-condensing |
||
|
Mechanical |
Dims. W*H*D |
115*160*360mm |
|
|
Weight |
10 kgs |
13 kgs |
|
|
Suitable |
Electric rolling door, Light, TV, Radio, PC, Motor…… |
||
