MODEL |
Units | HE-30 | HE-40 | HE-60 | HE-80 |
| CAPACITY: | |||||
| Loading factor 1:10 | kg | 12.8 | 19.2 | 27.4 | 38.5 |
| OVERALL DIMENSIONS: | |||||
| A - Width | mm | 724 | 785 | 880 | 1150 |
| B - Depth | mm | 965 | 1120 | 1194 | 1255 |
| C - Height | mm | 1143 | 1315 | 1555 | 1720 |
| WEIGHT AND SHIPPING INFORMATION: | |||||
| Net Weight | kg | 235 | 480 | 660 | 785 |
| Domestic shipping weight | kg | 246 | 492 | 720 | 803 |
| CYLINDER INFORMATION: | |||||
| Diameter | mm | 612 | 683 | 790 | 924 |
| Depth | mm | 435 | 525 | 560 | 574 |
| Volume | liters | 128 | 192 | 274 | 385 |
| Perforation size | mm | 4.8 | 4.8 | 4.8 | 4.8 |
| Perforation open area | % | 17 | 19 | 23 | 24 |
| CYLINDER SPEEDS: | |||||
| Wash | rpm | 48.5 | 46 | 43 | 39.5 |
| Distribution | rpm | 77 | 73 | 67 | 62 |
| Extract | rpm | 765 | 726 | 673 | 626 |
| DOOR OPENING AND HEIGHT: | |||||
| Diameter | mm | 400 | 400 | 450 | 520 |
| Height of door bottom above floor | mm | 355 | 475 | 569 | 616 |
| DRIVE INFORMATION: | |||||
| Number of motors | Number | 1 | 1 | 1 | 1 |
| Size of motor | kW | 1.5 | 2.2 | 3.7 | 5.5 |
| WATER INLETS | |||||
| ****** water size | DN | 20 | 20 | 20 | 20 |
| Cold water size | DN | 20 | 20 | 20 | 20 |
| Additional water Inlet | DN | 20 | 20 | 20 | 20 |
| Average ****** water consumption/ cycle | liters | 91 | 193 | 223 | 371 |
| Average COLD water consumption/cycle | liters | 174 | 102 | 106 | 174 |
| DRAIN OUTLETS AND CAPACITY: | |||||
| Number of drains | Number | 1 | 1 | 1 | 1 |
| Drain size | mm | 51 | 76.2 | 76.2 | 76.2 |
| Drain capacity | liter/min | 113 | 159 | 246 | 473 |
| STEAM INLET and CONSUMPTION: | |||||
| Steam inlet size | DN | 13 | 13 | 13 | 20 |
| Required steam to heat bath 10F (5.55C)LOW | kg | 0.5 | 5.3 | 8.4 | 14 |
| Required steam to heat bath 10F (5.55C)HIGH | kg | 0.6 | 6.6 | 9.2 | 16 |
| Average Steam consumption per cycle | kW | 7 | 15 | 22 | 35 |
| ELECTRICAL SERVICE: | |||||
| 380-480VAC, 50/60Hz, 3PH | Amps | 1.8 | 2.3 | 2.5 | 6.3 |
