| Load Capacity: | |||||
| Load capacity | kg | 11/12 | lbs | 26/30 | |
| Drum: | |||||
| Diameter | mm | 710 | in. | 28 | |
| Depth | mm | 530 | in. | 21 | |
| Volume | dm³ | 210 | cu.ft. | 7.8 | |
| Wash speed | g/1' | 45 | r.p.m. | 45 | |
| Extract speed | g/1' | 500 | r.p.m. | 500 | |
| Filter capacity: | |||||
| Nylon filter 1 | m² | 3 | sq.ft. | 32.2 | |
| Ecological type | lt | 50 | U.S.gals | 13.2 | |
| Decolorating filter | Ø | 1 Ø 190 | Ø | 1 Ø 7.5 | |
| Still: | |||||
| Still 1 | lt | 70 | U.S.gals | 18.5 | |
| Tanks: | |||||
| 1 st tank | lt | 120 | U.S.gals | 32 | |
| 2nd tank | lt | 65 | U.S.gals | 17.2 | |
| Heating elements: | |||||
| Drying | KW | 4,2 | KW | 4,2 | |
| Still | KW | 6 | KW | 6 | |
| Motors: | |||||
| Wash | KW | 1,1 | KW | 1.1 | |
| Extract 1/2 | KW | 1,1 | KW | 1.1 | |
| Fan | KW | 0,75 | KW | 0.75 | |
| Pump | KW | 0,55 | KW | 0.55 | |
| Filter | KW | 0,35 | KW | 0.35 | |
| Air compressor | KW | 0,35 | KW | 0.35 | |
| Refrigeration compressor | KW | 2,2 | KW | 2.2 | |
| Overall dimensions: | |||||
| Width (A) | mm | 1000 | in. | 39.3 | |
| Depth (B) | mm | 1900 | in. | 75 | |
| Height (C) | mm | 1950 | in. | 76.8 | |
| Weight: | |||||
| Weght | kg | 1050 | lbs | 2310 | |
| Installation data: | |||||
| Water inlet | Ø | 1/2" | Ø | 1/2" | |
| Water drain | Ø | 1/2" | Ø | 1/2" | |
| Min.water pressure | bar | 1,5 | p.s.i. | 25 | |
| Steam supply | Ø | 1/2" | Ø | 1/2" | |
| Condense exhaust | Ø | 1/2" | Ø | 1/2" | |
| Max.steam presure | bar | 4,5 | p.s.i. | 64 | |
| Air pressure | bar | 8 | p.s.i. | 116 | |
