Feature:
- Standards: conforming to USBV1.0, 1.1 and 2.0 and EIA RS-232.
- USB signals: VCC, DATA+, DATA-, GND and FG..
- RS-232 signals: DCD RXD TXD DTR GND DSR RTS CTS RI
- Working mode: asynchronous point-to-point.
- Direction control: adoption of automatic data stream control for automatic recognition and control of data transmission direction.
- Baud rate: 300-921.6Kbps, automatic detection of the transmission rate of the serial interface signal.
- Transmission distance: 5 meters for RS-232 and less than 5 meters for USB
- Interface protection: ±15KV electrostatic protection.
- Interface forms: B interface female connector and DB9 male connector for USB.
- Signal indication: 9 indicator lights for Power (PWR), Send (TXD) and Receive (RXD).
- Transmission media: twisted-pair cable or shielded cable.
- Dimensions: 1530mm×33mm×16mm.
- Working environment: -25℃ to 70℃, relative humidity 5% to 95%.
- Windows95/98/2000/XP/Vista and IMAG are supported.
- Both BUS and external power supply are supported.
