| IFOV (spatial resolution) | 5.6 mRad | ||
| Resolution | 80x60 (4,800 pixels) | ||
| Field of view | 19.5 °H x 26 °V | ||
| Wireless connectivity | Yes | ||
| Fluke Connect™ app compatible | Yes, with included wireless SD card (where available) | ||
| Focus system | Fixed focus 46 cm (18 in) and beyond | ||
| Ruggedized display | 3.5 inch diagonal (portrait format) | ||
| Rugged, ergonomic design for one-handed use | Yes | ||
| Thermal sensitivity (NETD) | ≤ 0.15 °C at 30 °C target temp (150 mK) | ||
| Temperature measurement range (not calibrated below -10 °C) | -20 °C to +250 °C (-4 °F to +482 °F) | ||
| Level and span | Smooth auto and manual scaling | ||
| Fast auto toggle between manual and auto modes | Yes | ||
| Fast auto-rescale in manual mode | Yes | ||
| Minimum span (in manual mode) | 2.5 °C | ||
| Minimum span (in auto mode) | 5 °C | ||
| Built-in digital camera (visible light) | 2 megapixel industrial performance | ||
| Frame rate | 9 Hz only | ||
| Data Storage and Image Capture | |||
| Extensive SD memory system | Removable 4 GB SD memory card and 8 GB wireless SD card (where available) | ||
| Direct download via USB-to-PC connection | |||
| Image capture, review, save mechanism | One-handed image capture, review, and save capability | ||
| File formats image | Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2) | ||
| No analysis software required for non-radiometric (.bmp, .jpg) files | |||
| Memory review | Thumbnail view navigation and review selection | ||
| Software | SmartView® software, Fluke Connect™, and SmartView® Mobile app—full analysis and reporting software | ||
| Export file formats with SmartView® software | BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF | ||
| Battery | |||
| Batteries (field-replaceable, rechargeable) | One lithium ion smart battery pack with five-segment LED display to show charge level | ||
| Battery life | Four+ hours continuous use per battery pack (assumes 50% brightness of LCD and average usage) | ||
| Battery charge time | 2.5 hours to full charge | ||
| AC battery charging system | In-imager charging. AC mains adapters included in 9 Hz versions. Optional two-bay AC battery charger (110 V AC to 220 V AC, 50/60 Hz) or optional 12 V automotive charging adapter. | ||
| AC operation | AC operation with included power supply (110 V AC to 220 V AC, 50/60 Hz). AC mains adapters included. | ||
| Power saving | User selectable sleep and power off modes | ||
| Temperature Measurement | |||
| Accuracy | ± 2 °C or 2% (at 25 °C nominal, whichever is greater) | ||
| On-screen emissivity correction | Yes (both number and table) | ||
| On-screen reflected background temperature compensation | Yes | ||
| Color Palettes | |||
| Standard palettes | 3: Ironbow, blue-red, grayscale | ||
| General Specifications | |||
| Infrared spectral band | 9 μm to 15 μm (long wave) | ||
| Operating temperature | -10 °C to +50 °C (14 °F to 122 °F) | ||
| Storage temperature | -20 °C to +50 °C (-4 °F to 122 °F) | ||
| Relative humidity | 10% to 95%, non-condensing | ||
| Center-point temperature measurement | Yes | ||
| Safety standards | CSA (US and CAN): C22.2 No. 61010-1-04, UL: UL STD 61010-1 (2nd Edition), ISA: 82.02.01 | ||
| Electromagnetic compatibility | EN 61326-1:2006 IEC 61326-1:2005 | ||
| C Tick | IEC/EN 61326-1 | ||
| US FCC | EN61326-1; FCC Part 5 | ||
| Vibration | 2G, IEC 68-2-6 | ||
| Shock | 25G, IEC 68-2-29 | ||
| Drop | Engineered to withstand 2 meter (6.5 feet) drop | ||
| Size (H x W x L) | 28.4 cm x 8.6 cm x 13.5 cm (11.2 in x 3.4 in x 5.3 in) | ||
| Weight (battery included) | 0.726 kg (1.6 lb) | ||
| Enclosure rating | IP54 (protected against dust, limited ingress; protection against water spray from all directions) | ||
| Warranty | Two-years (standard), extended warranties are available | ||
| Recommended calibration cycle | Two-years (assumes normal operation and normal aging) | ||
| Supported languages | Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish | ||
