eatures
Hardware
High Speed (4.7 LPS)
High Relability
Clamshell Splash Resistant Design
Embedded Power Supply
Two Color Capable
Recessed Cable Connections
Small Footprint
Paper Window
Swappable Communication Interfaces
“Drop In & Print” Paper and Ribbon Loading
Prints Up to 3 Copies At Once
Digitally Signed Drivers (WHQL)
Installation CD Included
Software
The Included Receipt Redesign Software
allows you to EASILY:
Add Images (Logos, Coupons and More)
Create a Virtual Serial Port for Legacy Applications
Configure an Ethernet Interface
Configure Memory Switch Settings
StarIO SDK
onnectivity
ote: Connections in b bo ol ld d are supported;
ayed-out connection types may be
pported by special request.
9-Pin Serial
25-Pin Serial
Parallel
USB
Powered USB
Ethernet
WiFi
Dual 9-Pin Serial/USB
Virtual Serial Port to USB
Virtual Serial Port to Ethernet
Virtual TCP/IP Port
rivers
Windows® XP
Vista (32 bit / 64 bit)
Windows 7 (32 bit / 64 bit)
Server 2008 (32 bit / 64 bit)
CE
XP Embedded
POS for .NET
OPOS™
JavaPOS™
USB Vendor Class
Linux™ CUPS
Mac OS X CUPS
What's Included
Cutter (SP742), Tear Bar (SP712) or Journal Model
5 ft. Power Cord
Embedded Power Supply
58mm Guide
Power Switch Cover
CD Including Drivers with Software Utilities
Setup Guide
Optional Accessories
Ticket Alarm Buzzer (BU01-24-A)
Wall Mount Bracket (WB-S700)
Vertical Stand Kit (VS-S700)
Putty or Gray Color Housing
echnical Specifications
Print Method: 9 Pin Impact Dot Matrix
Print Speed: 4.7LPS (13 Receipts Per Minute)
Paper Width: 70mm (standard) / 58mm
(With Paper Guide)
Paper Thickness: 0.06 - 0.08mm
Emulation: Star Mode, ESC/POS™
Buffer: 8Kbytes
Power: 110 to 230 VAC
MCBF: 22 Million Lines
Cutter: 1 Million Cuts
Ribbons: RC700B = 3M Characters
RC700BR = 1.5M Characters, Bla
.075M Characters, Re
Warranty US and Canada: 3-Year Limited Warranty, Plus Optional Extended Services Agreement Policies (Extend-A-Star and Swap-A-Star)
or Further Information
