Cảm Biến Tải Cas Loadcell Sba 100kg

Max. capacity

kgf

20, 50, 100, 200, 500, 1tf, 2tf, 3tf, 5tf

Rated output
Zoro balance

mV/ V
mV/ V

3.0 ± 0.3
0 ± 0.03

Accuracy class

D3

C3

Combined error
Repeatability
Creep for 30min.
Temperature effect on
           Zero Value
           Output value

%
%
%

%/ 10℃
%/ 10℃

0.03
0.01
0.03

0.028
0.015

0.02
0.01
0.017

0.014
0.011

Excitation
           Recommended
           Maximum
Resistance
           Input
           Output
           Insulation

V
V

Ω
Ω
MΩ

10
15

400 ± 25
350 ± 3.5
＞2,000

Compensated temperature range
Operating temperature range

℃
℃

-10 to +40
-30 to +80
