Model |
BL-75 |
||
|
Speed |
Forward |
6 speeds |
|
|
Reverse |
2 speeds |
||
|
Tilling |
4 (2 speeds by charging auxiliary sprockets) |
||
|
Tilling width |
480-600mm(18-7/8 -- 23-5/8in) |
||
|
No. of blades |
14-16 |
||
|
Tire |
5--12 |
||
|
Brake |
Inner expansion type |
||
|
Main clutch |
Dry multi-plate type |
||
|
Wheel tread |
390-780mm(15-3/8 -- 30-3/4in) |
||
|
Weight(without engine) |
179kg(394.6lbs) |
||
|
Engine |
Type |
Horizontal, water-cooled, 4-cycle diesel engine |
|
|
Model |
RT70 |
RT80 |
|
|
Fuel |
Light diesel oil (SAE No. 2-D) |
||
|
Rated output |
6.0hp/2,200rpm |
7.0hp/2,200rpm |
|
|
Max output |
8.0hp/2,400rpm |
8.0hp/2,400rpm |
|
|
Starting system |
Double speed handle manual |
||
|
Cooling system |
Radiator cooling |
||
|
Weight |
67kg/137.7lbs |
77kg/168.8lbs |
|
|
Measurements (with rotary) |
Length |
2,050mm(80-11/16in) |
|
|
Width |
710mm(27-15/16in) |
||
|
Height |
1,235mm(48-9/16in) |
||
