Mô tả sản phẩm: Bcsee BM-S65C
| Model | BM-S70C | BM-H70C | BM-S65C | BM-H60C | BM-S42C |
| Image Sensor | 1/3"SONY | 1/3" SHARP | 1/3"SONY | 1/3" SHARP | 1/3"SONY |
| TV System | PAL/NTSC | ||||
| Horizontal Resolution | 700TV Lines Low Illumination, DWDR,OSD (DNR, PM, MD) | 700TV Lines Low Illumination DWDR, OSD (DNR, PM, MD) | 650TV Lines Low Illumination DWDR, OSD (DNR, PM, MD) | 600 TV Lines Low Illumination | 420 TV Lines Low Illumination |
| Pixels | ICX811AK+ EFFIO-E | RJ2341+ | ICX639BK+ | RJ2365+ | ICX633BK+CXD3142 |
| RJ9H | RJ9H | 36B15 | |||
| Effective Pixels | NTSC:976(H)×494(V), | NTSC:976(H)×494(V), | NTSC:768(H)×494(V), | PAL: 752(H)×582(V), | PAL: 500(H)×582(V) |
| PAL:976(H)x582(V) | PAL:976(H)x582(V) | PAL:752(H)x582(V) | NTSC: 768(H)×494(V) | NTSC: 510(H)×492(V) | |
| Sync System | Internal | ||||
| IR LED | NO | ||||
| IR Series Distance | NO | ||||
| Lens | 3.6mm Board Lens | ||||
| IR Status | Under 10 Lux By CDS | ||||
| IR Power On | CDS Auto Control | ||||
| Usable Illumination | 0.001 Lux/F2.0 | 0.01 Lux/F2.0 | |||
| S/N Ratio | ≥48dB (AGC OFF) | ||||
| Gamma Correction | 0.45 | ||||
| Video Out | Composite Signal (1.0Vp-p, 75Ω) | ||||
| Scanning System | PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec | ||||
| Electronic Shutter Time | Auto:PAL 1/50-1/100,000Sec;NTSC 1/60-1/100,000Sec | ||||
| Operation Temperature | -10℃ ~ +50℃ RH95% Max | ||||
| Storage Temperature | -20℃ ~ +60℃ RH95% Max | ||||
| White Balance | Auto | ||||
| Power Source | DC12V 450mA | ||||
| Dimension | ￠119 x 56(H) mm | ||||
| Weight | 340g | ||||
