Mô tả sản phẩm: Seenedge G5P31371
| Model No: (NTSC) |
Hi Resolution | G5N31371 | G5N41371-F | G5N41371-G | |
| MED Resolution | G5N32371 | G5N32161 | G5N42371-F | G5N42371-G | |
| Model No: (PAL) |
Hi Resolution | G5P31371 | G5P41371-F | G5P41371-G | |
| MED Resolution | G5P32371 | G5P32161 | G5P42371-F | G5P42371-G | |
| CCD Type | 1/3 " SHARP | 1/3 " SONY | 1/4 " SHARP | ||
| Image Area | 4.9mm x 3.7mm(1/3"CCD) | 1/4"CCD | |||
| Pickup Elements |
NTSC | High Resolution : 768 (H) X 494 (V), 1/3" IT CCD | |||
| Medium Resolution : 510 (H) X 492 (V), 1/3" IT CCD | |||||
| PAL | High Resolution : 752 (H) X 582 (V), 1/3" IT CCD | ||||
| Medium Resolution : 512 (H) X 582 (V), 1/3" IT CCD | |||||
| Scanning System |
NTSC | 2:1 Interlace V:60Hz, H:15.750KHz | |||
| PAL | 2:1 Interlace V:50Hz, H:15.625KHz | ||||
| Sync System | Internal | ||||
| Video Output | 1Vpp Composite Output,75 ohms | ||||
| S/N Ratio | 50dB | ||||
| Resolution | High Resolution : 480 TV Lines ( Horizontal ) | ||||
| Medium Resolution : 380 TV Lines ( Horizontal ) | |||||
| Lens Mount | C or CS Mount | ||||
| Gamma Correction | 0.45 | ||||
| Ambient | -10 ~ 50°C; 30 ~ 90% RH | ||||
| Dimensions | 66(W) x 50(H) x 100(D)mm | ||||
| Weights | Approx. 265g | ||||
| Iris Control | Video Out / DC Iris | ||||
| BackLight Compensation | ON/OFF | ||||
| Gain Control | AUTO | ON/OFF | Auto | ||
| Power Source | DC12V | ||||
| Power Consumption | 1.5W | 2.8W (Max) | |||
| Minimum Illumination | 0.5 Lux (F 1.4) | 0.01Lux (F1.4) | Color to B/W under 1 Lux condition 0 Lux withing about 60 feet (IR ON) |
||
| White Balance | Auto tracking | ||||
| Flickless Control | ON/OFF | ||||
| Indoor / Outdoor | Switchable | ||||
| Shutter Control | Auto : 1/60 (1/50) to 1/100,000 Sec. | ||||
| Mirror Function | On/Off | No | On/Off | ||
| IR Cut Filter | OPTIONAL | ||||
| Line Pass Filter | 2000v/1usec/100Hz | ||||
| LED | No | No | IR LED (Wavelength 850nm) |
White Ligh (visable light) |
|
| Led On/Off CTRL | No | No | Auto or manual adjustable by variable resistance on rear pannel |
||
