Mô tả sản phẩm: Kavass CLG-8804
Specification
|
CLG-8804
|
CLG-8808
|
CLG-8816
|
|
Channel&Compression
|
4CH H.264
|
8CH H.264
|
16CH H.264
|
|
Video format
|
1.0Vp-p/75Ω,BNC×4
|
1.0Vp-p/75Ω,BNC×8
|
1.0Vp-p/75Ω,BNC×16
|
|
Video input
|
1.0V p-p/75Ω, BNC×1, VGA
|
|||
Video output
|
1.0V p-p/75Ω BNCX1
|
|||
LOOP output
|
1.0Vp-p/75Ω,BNC×4
|
1.0Vp-p/75Ω,BNC×8
|
1.0Vp-p/75Ω,BNC×16
|
|
SPOT output
|
1.0Vp-p/75Ω,BNC×1
|
|||
YpbPr output resolution
|
1920×1080i50/1920×1080i60
|
|||
HDMI output resolution
|
1920×1080i50/1920×1080i60
|
|||
VGA output resolution
|
1280×1024
|
|||
Record resolution CIF
|
Not support
|
8CH Realtime
|
16CH Realtime
|
|
Record resolution D1
|
4CH Realtime
|
8CH Realtime
|
16 fps/channel
|
|
Record mode
|
Manual/Sensor/Timer/Motion detection
|
|||
Playback
|
4CH Simultaneously
|
8CH Simultaneously
|
16CH Simultaneously
|
|
Network resolution/fps
|
CIF each channel>20 fps
|
|||
Audio input/output
|
4CH/1CH
|
8CH/1CH
|
16CH/1CH
|
|
Alarm input
|
4
|
8
|
16
|
|
Alarm output
|
Relay output, NO(Normal open), NC(Normal close), COM
|
|||
Alerm trigger
|
Sensor alarm,motion detection alarm,video loss alarm,disk-full pre-alarm
|
|||
Network port
|
RJ-45
|
|||
PTZ
|
RS-485
|
|||
USB port
|
USB2.0 X2
|
|||
Mouse
|
YES
|
|||
Hard disk
|
Support Four 2TB SATA HDD
|
|||
DVD-RW
|
Optional
|
|||
Mobile
|
windows Mobile, Symbian, Blackberry, Android, iPhone
|
|||
Remote controller
|
YES
|
|||
Power Supply
|
220V/110V PC ATX Adaptor
|
|||
Weight
|
About 8Kg with package
|
|||
External Dimension(mm)
|
435mm(L) ×415mm(W) ×103mm(H)
|
|||
