Lapp Kabel FR-6387 OS 1x2x1.5 300/500V (3805880)

Application range
Specially designed to be use for wiring applications in critical life safety system in public and industrial buildings such as airports, hotels, hospitals, subways, train stations, etc.
In building management systems, emergency lightings, standby power supplies, lifts and elevators
Plant engineering and construction, industrial machinery, power station

Product features
Flame retardant acc. to IEC 60332-1-2 and to IEC 60332-3-22
Halogen free acc. to IEC 60754-1
Acid and corrosive gases acc. to IEC 60754-2
Smoke density test acc. to IEC 61034

Approvals (Norm references)
Fire test certified and approved to BS 6387 Cat. CWZ
Approved to SS 299 PLS Class 1A
Approved to IEC 60332-3-22 Cat. A

Product Make-up
Stranded plain annealed copper wire
Mica based fire resistance tape
XLPE insulation
Mylar tape wrapping
Aluminium/mylar tape screen in contact with drain wire
LSHF outer sheath
Colour: orange

Technical data
Core identification code:
– Pair: BK/RD or BU/BN
– Multipair: BK/WH with numbering
– Multicore: 3C and above WH with numbering
Approvals: BS 6387 Cat. CWZ, SS 299-1 PLS Class 1A
Conductor stranding: acc. to IEC 60228 Cl. 2
Minimum bending radius: 10 x cable diameter
Nominal voltage: U0/U: 300/500 V
Test voltage: 2000 V, Core-Core
Temperature range: -30°C to +90°C
